3-axle U-shaped rear dump trailer

Product Introduction
Rear dump trailert Widely used in construction engineering, municipal engineering, road construction, sanitation, mining, limestone kiln, stone plant, cement plant, cement plant, starch plant, brick plant, fire resistant plant, coking plant, phosphate fertilizer plant, chemical fertilizer plant, concentrator plant, construction team, railway station, coal yard, bee coal yard, wharf, etc.Can save manpower greatly, reduce labor intensity.
Product specification
Product Name | 3 Axle 35/40 CBM Tipper Trailer 60 Tons Dump Semi Trailer |
Function | Transport heavy Stone and Sand |
Overall dimension | 9000x2500x3600mm |
Loading weight | 60000KGS to 80000KGS |
Main beam | Material is Q345B, The height of the beam is 500 mm, upper plate is16mm, down plate is 18mm,middle plate is 10mm. |
Side beam | 22mm channel steel |
Traction pin | JOST Brand, optional 2" or 3.5" |
Land gear | Standard 28ton |
Axle | 13ton for each axle |
Axle brand | FUWA Brand axle |
Suspension type | 3 axle mechanical suspension |
Leaf spring | 10/10/10 90mm*13mm*10pcs |
Rim | 9.00-22.5 12pcs |
Tire | 1200R20 triangle brand |
Tire quantity | 12 units |
Box Size | Bottom 8MM Size 6MM |
Valve | WABCO VALVE |
Brake Chamber | 6 big chamber brake system |
Tool box | 1 unit 1m*0.5m*0.5m |
Spare wheel carrier | 2 units |
Side marker lamp | LED type |
